Fixed speed, T1
Model：DH-F10S
Power Supply: 220-240V~50Hz
COP: 4.42
Refrigeration: R410A
Compressor: GMCC / Fixed speed
Air side heat exchanger: Fin-coil
Motor: AC motor
Fan: Low Noise Axial Fan; Air flow volume: 2,500m³/ h
Throttling Mode: EXV
Water side heat exchanger: Tube-in-Tube
Water pipe connection: Male thread, G1″
Ambient Temp. Range: -15℃~46℃
Leaving Water Temp. Range: 20℃～55℃ (Default: 50℃)
DC Inverter, T1
Model：DH-V10
Power Supply: 220-240V~50/60Hz
COP: 4.34
Refrigeration: R410A
Compressor: GMCC / DC Inverter Rotary
Air side heat exchanger: Fin-coil
Motor: AC motor
Fan: Low Noise Axial Fan; Air flow volume: 2,500m³/ h
Throttling Mode: EXV
Water side heat exchanger: Tube-in-Tube
Water pipe connection: Male thread, G1″
Ambient Temp. Range: -15℃~46℃
Leaving Water Temp. Range: 20℃～55℃ (Default: 50℃)
It extracts heat from ambient air through a refrigerant cycle and transfers it into water, producing hot water with a COP of 3-4 and cutting water heating energy costs by roughly 70% compared with electric heaters.
Commercial models range from 20 kW to 400 kW, suitable for hotels, hospitals, schools, swimming pools and industrial process hot water.
Yes. Ultra-low-temperature models are engineered to work reliably down to about -25°C ambient, using enhanced vapor injection compressors to maintain heating performance in winter.
A single unit can supply multiple insulated storage tanks through a circulation loop. We also provide matched tank and controller packages for complete hot water systems.
No. Connect the water pipes and power supply, set the controller, and the unit self-adapts. Our engineers provide remote commissioning guidance for every project.
