Fixed speed, Normal Ambient
Model: DH-F20S
Power Supply: 380-415V 3N~50Hz
EER: N/A (heating only)
COP: 4.42
Refrigeration: R410A
Compressor: GMCC / Fixed speed
Air side heat exchanger: Fin-coil
Motor: AC motor
Fan: Low Noise Axial Fan; Air flow volume: 5,000m³/h
Water side heat exchanger: Tube-in-Tube
Ambient Temp. Range: -15℃~46℃
Leaving Water Temp. Range: 20℃~55℃ (Default: 50℃)
Unit Dimension (W×H×D): 1040×850×410 mm
Package Dimension (W×H×D): 1170×1020×560 mm
Net Weight: 94 kg
Operation Weight: 107 kg
Gross Weight: 118 kg
DC Inverter, Normal Ambient
Model: DH-V20S
Power Supply: 380-415V 3N~50Hz/60Hz
EER: N/A (heating only)
COP: 4.31
Refrigeration: R410A
Compressor: GMCC / DC Inverter Rotary
Air side heat exchanger: Fin-coil
Motor: AC motor
Fan: Low Noise Axial Fan; Air flow volume: 5,000m³/h
Water side heat exchanger: Tube-in-Tube
Ambient Temp. Range: -15℃~46℃
Leaving Water Temp. Range: 20℃~55℃ (Default: 50℃)
Unit Dimension (W×H×D): 1040×850×410 mm
Package Dimension (W×H×D): 1170×1020×560 mm
Net Weight: 96 kg
Operation Weight: 109 kg
Gross Weight: 118 kg
DC Inverter, Normal Ambient
Model: DH-V20
Power Supply: 220-240V~50Hz/60Hz
EER: N/A (heating only)
COP: 4.31
Refrigeration: R410A
Compressor: GMCC / DC Inverter Rotary
Air side heat exchanger: Fin-coil
Motor: AC motor
Fan: Low Noise Axial Fan; Air flow volume: 5,000m³/h
Water side heat exchanger: Tube-in-Tube
Ambient Temp. Range: -15℃~46℃
Leaving Water Temp. Range: 20℃~55℃ (Default: 50℃)
Unit Dimension (W×H×D): 1040×850×410 mm
Package Dimension (W×H×D): 1170×1020×560 mm
Net Weight: 95 kg
Operation Weight: 108 kg
Gross Weight: 118 kg
It extracts heat from ambient air through a refrigerant cycle and transfers it into water, producing hot water with a COP of 3-4 and cutting water heating energy costs by roughly 70% compared with electric heaters.
Commercial models range from 20 kW to 400 kW, suitable for hotels, hospitals, schools, swimming pools and industrial process hot water.
Yes. Ultra-low-temperature models are engineered to work reliably down to about -25°C ambient, using enhanced vapor injection compressors to maintain heating performance in winter.
A single unit can supply multiple insulated storage tanks through a circulation loop. We also provide matched tank and controller packages for complete hot water systems.
No. Connect the water pipes and power supply, set the controller, and the unit self-adapts. Our engineers provide remote commissioning guidance for every project.
