DC Inverter, T3
Model: DMC-V12N1T / DMC-V14N1T / DMC-V16N1T
Power Supply: 220-240V~50Hz / 60Hz
EER: 3.28/3.13/2.95
COP: 3.42/3.32/3.23
Refrigeration: R32
Compressor: GMCC / DC Inverter Rotary
Air side heat exchanger: Fin-coil
Motor: DC motor
Fan: Low Noise Axial Fan; Air flow volume: 4,100/4,100/4,100m³/h
Water side heat exchanger: Plate type HX
Ambient Temp. Range: Cooling 5℃~54℃; Heating -25℃~25℃
Leaving Water Temp. Range: Cooling 5℃~20℃; Heating 25℃~60℃
Unit Dimension (W×H×D): 1040×850×410 mm
Package Dimension (W×H×D): 1170×1020×560 mm
Net Weight: 104 / 105 / 106 kg
Gross Weight: 117 / 118 / 119 kg
It is a compact water chiller with inverter-driven DC compressors and fans that modulate cooling capacity from roughly 20% to 100%, saving up to about 40% energy compared with fixed-speed models at partial load.
Mini chillers are ideal for small commercial buildings, hotels, villas, laboratories, telecom shelters and process cooling where space, weight and quiet operation matter.
Low-speed operation keeps sound pressure levels around 52 dB(A) at 1 m on typical models, thanks to low-speed inverter fans and sound-insulated compressor compartments.
The full DC inverter mini chiller range covers approximately 8-30 kW per unit, and multiple units can be grouped to cover larger cooling loads.
Yes. Mini chillers connect directly to DERK fan coil units, cassette and duct units through a simple chilled-water loop, and we can supply a matched system for turnkey projects.
